HOBO Split-Core Bi-Polar DC Transducer Sensor
The HOBO split-core bi-polar DC transducer sensor measures up to 200 Amps of DC current in both flow directions.
Features
- Adjustable span range
- Small size, split-core for ease of installation
Your Price
$343.00
Stock
Check
Availability
Fondriest Exclusives
- Expedited repair and warranty service
- Lifetime technical support
- More
Overview
The HOBO split-core bi-polar DC transducer sensor measures up to 200 Amps of DC current in both flow directions.
Requirements (Logger Specific):
HOBO MX1100 series: a 4-20mA input cable (SD-MA-420) and external power provided by an AC adapter (AC-SENS-1)
HOBO UX120-006M or ZW series: a 4-20mA input cable (CABLE-4-20mA) and external power provided by an AC adapter (AC-SENS-1)
HOBO RX3000: an analog input module (RXMOD-A1)
HOBO U30: an analog input module (VIA)
HOBO H22: an analog input module (S-FS-CVIA)
- DC Amperage: (bi-polar)
- Measurement range: +/- 2 to +/- 200 (via span adjust)
- Accuracy (below 100A span): +/- .5 A
- Accuracy (above 100A span): +/- .5% full scale
- Sensor supply: 12 - 24 DC (15 VDC min. for currents > 120 A), 35 mA no-load to 110 mA at 200 A current
- Isolation: 600 VAC rms
- Operating temperature range: -30 to 60C (-22 to 140F)
- Humidity range: 10 - 90% non-condensing
- Response time: 2 sec.
- Output: (bi-polar) 4 - 20mA
- Dimensions: 3.1x2.8x1.4 in. (79x70x36 mm)
- Weight: 5.25 oz.
- Sensor opening: 1.1x.9 in. (28x23 mm)
- LED indications: single green blink=Norm, double green=Over Span, red+green=Over Limit, solid red=overload
Questions & Answers
Select Options
Products
0 Item Selected
Part #
Description
Price
Stock
Quantity
T-VER-971BP-200
Split-Core Bi-Polar DC Transducer Sensor, 200A
$343.00
Check Availability
Notice: At least 1 product is not available to purchase online
