HOBO Adjustable AC Current Switch Sensor
The HOBO adjustable AC switch sensor measures equipment runtime (time-of-use). Install around a current-carrying wire to provide a relay signal that indicates equipment is on or off.
Features
- Adjustable current threshold of 0.5 to 175 amps
Your Price
$125.00
Stock
Check
Availability
Fondriest Exclusives
- Expedited repair and warranty service
- Lifetime technical support
- More
Overview
The HOBO AC Current Switch measures equipment runtime (time-of-use). This UL-listed sensor has built-in on/off status lights and provides an adjustable current threshold of 0.5 to 175 amps. Install the sensor around a current-carrying wire to the equipment to be monitored and then connect the sensor to a compatible HOBO UX90 or UX120-017 data logger. Can be used with any state channel on UX120-017, UX90-001 or UX90-004 data loggers.
Amperage range: 0.5 to 175 Amps continuous
Sensor supply voltage: Induced from monitored conductor, with no external power required
Isolation: 600 VAC rms (max voltage when monitoring an uninsulated conductor
Status ratings: N.O. 1.0A @ 30 VAC/DC max, not polarity-sensitive
Dimensions: 5.9 x 5.1 x 2.3 cm (2.32 x 2.0 x 0.92 in)
Window opening: 0.5” x 0.6” (1.27 cm x 1.52 cm)
Questions & Answers
Select Options
Products
0 Item Selected
Part #
Description
Price
Stock
Quantity
CSV-A8
AC current switch sensor, adjustable
$125.00
Check Availability
Notice: At least 1 product is not available to purchase online
